欧曼10方不锈钢运水车
4X2
In Stock
Full Price:
￥185000.00
Deposit:
¥20000.00
Model：
Brand：特价车
Area：天津市
Source：Kangcheng
Publish Date：2022-12-26
Configuration：福田欧曼10方不锈钢运水车，270马力，出口转内销车辆。不含运费。
Brand：特价车
Area：天津市
Source：Kangcheng
Publish Date：2022-12-26
Configuration：福田欧曼10方不锈钢运水车，270马力，出口转内销车辆。不含运费。
Quantity：
Stock：50辆
Buy Now
- Product Description
-
10方不锈钢运水车
10m3Stainless steel water truck
底盘配置及参数
Chassis configuration and parameters车辆型号 vehicle model BJ5182GSS-1 Truck main dimension
整车主要尺寸参数Vehicle external dimensions(L×W×H)
整车外部尺寸（长×宽×高）8310×2500×3160 Drive 驱动型式 4×2 Wheelbase 轴距（mm） 4600 Tread 轮距（前/后）mm 2010/1865 Weight
质量参数Curb vehicle weight 整车整备质量（kg） 7004 Rated payload 额定装载质量（kg） 10866 Passengers 额定载客数（人） 3 GVW 总质量（kg） 18000 Truck performance
整车主要性能参数Maximum Speed 最高车速（km/h） 89 Maximum Climbing grade 最大爬坡度（%） 38 Engine
发动机Type 型号 WP10.270E32 EURO 3 Mechnical Emission 排量（L） 9.726 Power KW/HP 标定功率/标定转速（kw/rpm） 199/270(2200） Torque 最大扭矩/转速（N.m/rpm） 1100(1200-1600) Transmission
变速器Type 型号 Fast 9JS119T-B(Q) Clutch
离合器Type型式 φ430膜片弹簧离合器
φ430 Diaphragm spring clutchFront axle前桥 Type 型式 6.5T Rear axle后桥 Type 型式/主减速器速比 13T hub reduction, ratio 4.8
13T双级减速/4.8Suspension
悬挂Front 前悬挂/弹簧片数 Steel spring 纵置钢板弹簧+筒式减震器，9 Rear 后悬挂/弹簧片数 Steel spring纵置主、副钢板弹簧，9+6 Steering 转向器 AM75L AM75L Brake 制动系 Driving brake行车制动型式 Double pneumatic drum type双回路气压鼓式 Parking brake驻车制动型式 Energy storage spring air brake储能弹簧断气制动 Auxiliary brake辅助制动器 WEVB Egnine exhaust brake 发动机排气制动 Wheel and Tire 车轮数及轮胎规格 6+1/11.00R20 Fuel tanker 燃油箱(L) 380 基本配置basic configuration Air conditioning, manual cab lift, air bag seat, manual rearview mirror glass lifter, desert air filter, integral metal bumper, MP3+ radio +USB
空调、手动驾驶室举升、气囊座椅、手动后视镜玻璃升降器、沙漠空滤器、整体式金属小保险杠、MP3+收音机+USB上装配置及参数 Body configuration and parameters A.TANK BARREL 罐体 1. Tank Profile罐体截面 Round shape 圆形 2. Test pressure测试压力 Hydrostatic test to5 psi (35 Kpa) on each compartment. 每仓水压试验压力5pas (35Kpa) 3. Working pressure工作压力 Atmospheric.大气压 4. Capacity容积 10000L plus 3~5% ullage. 10000L+3-5%气相空间 5. Compartments分仓 Single compartment. 单仓 6. Interior weld finish罐体内部处理 Not polished or grinded (W-0). 不抛光，不打磨 7. Exterior weld finish罐体外部处理 Not polished or grinded (W-0). 不抛光，不打磨 8. Shell material罐体材料 Stainless steel 304 2B. 不锈钢304 2B a) Top顶板 3.7mm nominal. 名义厚度3.7mm b) Sides侧板 3.7mm nominal. 名义厚度3.7mm c) Bottom底板 3.7mm nominal. 名义厚度3.7mm 9. End Plate 尾板 Stainless steel 304 2B, 3.7mm nominal. 名义厚度3.7mm
All single heads dished and flanged. 蝶形封头10. Bulkhead隔舱 Nil. 无 11. Baffle / Surge Heads 防浪板 Stainless steel 304 2B, 3.7mm nominal. 名义厚度3.7mm Dished with flap. 蝶形带清洁环 1 pcs.1只 12. Spill molding and rollover protection罐顶集液槽 Stainless steel around the dome with drain hose.人孔周围有排水管 14. Outer rings外加强圈 304-2B stainless steel, 60mm height, 3mm nominal, continuously welded. 不锈钢304 2B， 60mm高，名义厚度3mm，连续焊接 15. Frame车架 Carbon steel independent.碳钢 16. Loaders and brackets承重支架 Carbon steel. 碳钢 B. TANK FITTINGS AND PIPING罐体部件及管道 1. Manholes人孔 20" diameter with 6 stainless steel wing nuts, located at the top center
1 pc. 20寸6爪人孔1只2. Pressure Vacuum Vent呼吸阀 Two per compartment. 6~12 kPa pressure, 2~4 kPa vacuum.
每仓2只，6~12 kPa 压力, 2~4 kPa 真空6.Foot valve底阀 Nil. 无 7. Discharge system 卸料系统 3” diameter discharge with 3" diameter butterfly valve, 3" stainless steel male camlock coupling and quick cap, located at the back of the tank.
卸料蝶阀位于罐体尾部，无操作箱8. Piping管道 Nil. 无 9. Thermometer温度计 Nil. 无 10. Steam trace蒸汽管道 Nil. 无 11. Overfill Prevention防溢流 Nil. 无 12. Tow Hook 拖钩 Nil. 无 13. Product Indicators介质指示器 Nil. 无 C. ACCESSORIES附件 1. Ladder 爬梯 Stainless steel, 400mm wide, with non skid rungs and lateral handles, mounted at right middle of tanker.
不锈钢爬梯，400mm宽，安装在右侧中部2. Walkway 走道 Extruded aluminium around dome. 铝合金走道 3. Hose Carries软管存放箱 1 no, hose carrier (round tubes) to fit ?159 x 6meter (236") hose close type complete with brackets to be installed at the right side.
一根软管存放箱在罐体右侧4. Hose软管 Firemen type flexible discharge hoses, 30m 3" for discharge. and flexible plastics suction hoses, 5.9m 3"for suction, 3" female camlock coupling at both ends.
消防水带3寸，30米长一端带阴端接头5. Motor Pump汽油泵 BRIGGS & STRATTON Gasoline motor , 4 stroke motor, fuel tank capacity 4.0 liters of gasoline, WB30 pump with a 3" input and outlet diameter, 7m suction head, discharge capacity 900L/min (238Gal/min) pump head pressure 33 m, weight 30kg.
百力通汽油马达+WB 30泵7. Rear Bumper 后保险杠 Aluminium member to accommodate light assembly and number plate to cover full width of the tank.
保险杠上部为 铝合金灯支架及牌照支架，下部为碳钢保险杠。Steel bumper with ground clearance 500mm approx.
后保险杠离地间隙约500mm10. Mudguard挡泥板 Aluminum over suspension and the upper coupler.
Mud flaps rigid plastic at the rear. 铝合金挡泥板带挡泥皮11. Lights & Wiring电路系统 24V. ISO 1185 7 pin socket. 24伏，ISO 1185 七芯插座 12. Reverse alarm倒车蜂鸣器 Nil. 无 13. Connector Box握手盒 At the center in the front dishend在前面 14. Sticker贴纸 50mm wide red-white reflective sticker, mounted at both sides and rear bump. 50mm宽红白反光贴纸 16. Fire Extinguisher灭火器 8kg , 2Pcs. 两个8公斤灭火器
Carbon steel extinguisher holder located on the landing gear on the curb side.17. Drains hose排水管 water drains hose 2", installed at the back of spill molding
集液槽后面有2寸排水管21. Spare wheel bracket备胎架 1set一只碳钢篮式备胎架，安装于支腿后方
Carbon steel, basket type, located behind the landing gear.
